More Profiles and Fitting Parts

  • Gammafuge ST6/..
    Visible width:
    12 mm
    Material/sheet thickness:
    6 mm
    Load rating:
    Radlast 1500 kg bei Ø 150 mm, B = 100 mm
    Load rating trucks:
    600 kN (DIN 1072)

    Gammafuge ST6/..

    • extremely high load-bearing capacity
    • optimum edge protection
    • load transmission with steel dowels

    Details data sheet

  • Gammafuge ST10/..
    Visible width:
    20 mm
    Material/sheet thickness:
    10 mm
    Load rating:
    Radlast 1500 kg bei Ø 150 mm, B = 100 mm
    Load rating trucks:
    600 kN (DIN 1072)

    Gammafuge ST10/..

    • extremely high load-bearing capacity
    • optimum edge protection
    • load transmission with steel dowels

    Details data sheet

  • Sinusfuge ST6/..
    Visible width:
    12 mm
    Material/sheet thickness:
    6 mm
    Load rating:
    Radlast 1500 kg bei Ø 150 mm, B = 100 mm
    Load rating trucks:
    600 kN (DIN 1072)

    Sinusfuge ST6/..

    • extremely high load-bearing capacity
    • optimum edge protection
    • load transmission with steel dowels

    Details data sheet

  • VA.10.230/..
    Movement horizontal:
    100 mm (±50 mm)
    Visible width:
    230 mm
    Maximal joint width:
    60 mm
    Load rating:
    Radlast 4000 kg bei Ø 150 mm, B = 100 mm

    VA.10.230/..

    • high load-bearing capacity
    • visible surface in high-grade steel
    • anti-slip surface

    Details data sheet

  • VA.10.230/.. F
    Movement horizontal:
    100 mm (±50 mm)
    Visible width:
    230 mm
    Maximal joint width:
    60 mm
    Load rating:
    Radlast 4000 kg bei Ø 150 mm, B = 100 mm

    VA.10.230/.. F

    • high load-bearing capacity
    • visible surface in high-grade steel
    • anti-slip surface

    Details data sheet

  • MST48/..
    Movement horizontal:
    20 mm (±10 mm)
    Movement vertical:
    20 mm (±10 mm)
    Visible width:
    48 mm
    Maximal joint width:
    40 mm

    MST48/..

    • suitable for all types of covering
    • high load-bearing capacity
    • replaceable flexible insert

    Details data sheet

  • BU2000
    Movement horizontal:
    40 mm (±20 mm)
    Maximal joint width:
    80 mm
    Supply length:
    3 mtr

    BU2000

    • suitable for all types of covering
    • with loose/fixed flange
    • sealing insert approved by the building authorities

    Details data sheet

  • BU2500
    Movement horizontal:
    40 mm (±20 mm)
    Maximal joint width:
    80 mm
    Supply length:
    3 mtr

    BU2500

    • with loose/fixed flange
    • for insulated constructions
    • sealing insert approved by the building authorities

    Details data sheet

  • Fugenband BF20
    Movement horizontal:
    40 mm (±20 mm)
    Movement vertical:
    40 mm (±20 mm)
    Movement a long the joint
    40 mm (±20 mm)
    Total width:
    355 mm

    Fugenband BF20

    • sealing insert approved by the building authorities
    • three-dimensional absorption of movements

    Details data sheet

  • Fugenband BF40
    Movement horizontal:
    80 mm (±40 mm)
    Movement vertical:
    80 mm (±40 mm)
    Movement a long the joint
    80 mm (±40 mm)
    Total width:
    390 mm

    Fugenband BF40

    • sealing insert approved by the building authorities
    • three-dimensional absorption of movements

    Details data sheet
