LFK4/..

LFK4/..

  • with loose/fixed flange
  • covering separation
  • edge termination

Features

high edge protection, professional coating separation

Applications

parking decks, parking garages, underground garages, ramp crossings, pedestrian bridges, all industrial applications, shopping centres, railway stations, airports

Material

hot-dip galvanised steel, stainless steel V2A (V4A on request)

Covering Types

asphalt, concrete, screed, bitumen welding membrane

trafficability

passenger cars, trucks, fork-lifts

Formed parts

corner piece, end plate

Notes

Threaded bolt M12x35 mm with washer and nut, e=150 mm

Specification of profile height (h) from the lower edge of the loose flange.

Loose flange according to DIN, l=1500 mm

Solid flange joints should be fully welded through and ground flat on the sealing side.

Technical data

Material thickness fixed flange:
8 mm
Material thickness loose flange:
6 mm
Supply length:
3 mtr

Designs

Article No. Height (h) Recess (BxT)
LFK4/50 50 mm 140 x 20 mm
LFK4/60 60 mm 140 x 20 mm
LFK4/80 80 mm 140 x 20 mm

Special heights on request.

Technical design
Subject to technical change without notice
LFK4/..
