BBF124/.. combined with ALR.6

high load-bearing capacity
joint profile with loose/fixed flange
drain channel with loose/fixed flange

data sheet inquire now

We are also available by phone for further questions.

+49(0)8406/9294-0

Closed Opens at 07:00

tuesday: 07:00 - 16:00 Uhr
wednesday: 07:00 - 16:00 Uhr
thursday: 07:00 - 16:00 Uhr
friday: 07:00 - 13:00 Uhr
saturday: Closed
sunday: Closed
monday: 07:00 - 16:00 Uhr

Features

watertight, resistant to heavy loads, expansion insert can be replaced anytime, abrasion-, weather- and temperature-resistant (-40°C to +120°C), resistant to de-icing salt and waste water (alkalis, microbes, bacteria), high edge protection due to steel edges t=6 mm, grating with mesh size 30x10 mm (30x30 mm on request), grid lock inclusive

Applications

parking decks, parking garages, underground garages, ramp crossings, pedestrian bridges, all industrial applications

Material

joint profile: hot-dip galvanised steel, (stainless steel on request), EPDM expansion insert, joint tape BF made of EPDM with lateral bonding flanges made of non-combustible fleece on the top and bottom sides

drain channel: stainless steel V2A (V4A on request)

Covering Types

asphalt, concrete, screed, bitumen welding membrane

trafficability

passenger cars (trucks on request)

Notes

Version also available with BBF144/..

For stainless steel, the general cleaning and care instructions must be observed (see also download area).

Possible profile height (h3) and channel depth (t*) on request.

Installation by our own fitters recommended.

Technical data

BBF124/..

Movement horizontal:: 35 mm (-15/+20 mm)
Movement vertical:: 20 mm (±10 mm)
Visible width:: 114 mm
Maximal joint width:: 65 mm
Color of expansion insert:: schwarz

ALR.6

Material thickness channel body:: 4 mm
Material thickness vertical base:: 5 mm

Designs

All hights can be combined

BBF124/..

Article No.	Profile height (h1)
BBF124/55	55 mm
BBF124/100	100 mm
BBF124/120	120 mm
BBF124/150	150 mm

ALR.6

Article No.	Steel grating width (b)	Channel height (h2)
ALR.6.150/51	150 mm	51 mm
ALR.6.150/66	150 mm	66 mm
ALR.6.200/51	200 mm	51 mm
ALR.6.200/66	200 mm	66 mm
ALR.6.200/86	200 mm	66 mm
ALR.6.250/51	250 mm	51 mm
ALR.6.250/66	250 mm	66 mm
ALR.6.250/86	250 mm	86 mm

Special heights on request.

BBF124/..

Technical design — Subject to technical change without notice

ALR.6

Downloads

data sheet PDF

BBF.124/55 ALR.6.150/51.dwg Auto CAD
