drain channel
ALR.8.200/.. stainless

ALR.8.200/..

  • high load-bearing capacity
  • with coating-flange

Features

permanently tight, corrosion-resistant, high flexibility (variable lengths, heights and widths), mesh size grating in 30x10 mm (30x30 mm on request)

Applications

parking decks, parking garages, underground garages, all industrial applications, shopping centres, railway stations, airports, exhibition halls

Material

hot-dip galvanised steel, stainless steel V2A (V4A on request)

Covering Types

coating

trafficability

passenger cars (trucks on request)

Formed parts

channel end piece (flange all around or upstand), corner piece, T-piece, cross piece, channel drain, 2-fold locking per grating

Notes

The individual channel elements are tightly welded together during installation on site.

For stainless steel, the general cleaning and care instructions must be observed (see also download area).

Installation by our own fitters recommended.

Technical data

Material thickness channel body:
4 mm
Material thickness mounting bracket:
5 mm
Supply length:
3 mtr
Steel grating width:
200 mm

Designs

Article No. Channel height (h) Recess (BxT)
ALR.8.200/90 90 mm 260 x 100 mm
ALR.8.200/120 120 mm 260 x 130 mm
ALR.8.200/150 150 mm 260 x 160 mm

Special heights on request.

Technical design
Subject to technical change without notice
ALR.8.200/..
