- suitable for all types of covering
- high load-bearing capacity
- with adhering flange
Für weitere Fragen stehen wir auch telefonisch zur Verfügung.
resistant to heavy loads, durable leak-proof, noncorrosive, high flexibility (variable lengths, heights and widths), mesh size of the steel grating in 30X10 mm or 30x30 mm possible
outdoor, multi-storey and underground park decks, all industrial applications, shopping centres, railway stations, airports, exhibition halls
hot-dip galvanised steel, high-grade steel V4A (on request)
asphalt, concrete, screed
truck (on request)
For this gutter are all accessories and fittings available., Rinnen-Endstück (Flansch umlaufend oder Aufkantung), corner piece, T piece, cross piece, Rinnen-Ablauf, 2 lock per grid
Our engineers and technicians can be of assistance during installation on request.
A leak-proof welding of several gutter-parts happens in the course of installing at the building site.
drainage slots are possible (on request).
For stainless steel gutters, the general cleaning and care instructions must be observed (see also www.buprofile.de - Download section).
- Material thickness bonding flange:
- 4 mm
- Material thickness vertical base:
- 5 mm
- Supply length:
- 3 mtr
- Steel grating width:
- 250 mm
|Article No.||Profile height||Recess (B⨉T)|
|ALR.2.250/59||59 mm||560 ⨉ 20 mm|
|ALR.2.250/79||79 mm||560 ⨉ 20 mm|
Other heights on request.
