ALR.2.150/..
- suitable for all types of covering
- high load-bearing capacity
- with adhering flange
Für weitere Fragen stehen wir auch telefonisch zur Verfügung.
+49(0)8406/9294-0
Features
resistant to heavy loads, durable leak-proof, noncorrosive, high flexibility (variable lengths, heights and widths), mesh size of the steel grating in 30X10 mm or 30x30 mm possible
Applications
outdoor, multi-storey and underground park decks, all industrial applications, shopping centres, railway stations, airports, exhibition halls
Material
hot-dip galvanised steel, high-grade steel V4A (on request)
Covering Types
asphalt, concrete, screed
trafficability
truck (on request)
Formed parts
Rinnen-Endstück (Flansch umlaufend oder Aufkantung), corner piece, T piece, cross piece, Rinnen-Ablauf, 2 lock per grid
Notes
Our engineers and technicians can be of assistance during installation on request.
A leak-proof welding of several gutter-parts happens in the course of installing at the building site.
drainage slots are possible (on request).
For stainless steel gutters, the general cleaning and care instructions must be observed (see also www.buprofile.de - Download section).
- Material thickness bonding flange:
- 4 mm
- Material thickness vertical base:
- 5 mm
- Supply length:
- 3 mtr
- Steel grating width:
- 150 mm
Article No. | Profile height | Recess (B⨉T) |
---|---|---|
ALR.2.150/49 | 49 mm | 460 ⨉ 20 mm |
ALR.2.150/59 | 59 mm | 460 ⨉ 20 mm |
ALR.2.150/79 | 79 mm | 460 ⨉ 20 mm |
Other heights on request.
