formed parts

Professional and water-tight construction at changes of direction, height steps as well as profile ends.

formed parts options

The following formed parts are available as standard for all profile types:

  • corner piece horizontal 30°-150°
  • corner piece vertical
  • T-piece
  • cross piece

Buchberger Profilsysteme

Corner piece horizontal

Buchberger Profilsysteme

Corner piece vertical

Buchberger Profilsysteme

T-piece

Buchberger Profilsysteme

Cross piece

Profile end designs

Buchberger Profilsysteme VA.8.95/..

Upstand h=50 mm

Buchberger Profilsysteme VA.8.95/..

Upstand  h = 150 mm

Buchberger Profilsysteme VA.8.95/..

End piece h = variable

Buchberger Profilsysteme VA.8.95/..

Corner piece vertical h = variable

Buchberger Profilsysteme VA.8.95/..

Cavetto 45 ° with end piece h = 50 mm

Buchberger Profilsysteme VA.8.95/..

Bevelling h=150 mm

Buchberger Profilsysteme VA.8.95/..F

Foil lift h = variable

Buchberger Profilsysteme VA.8.95/..F

Upstand  h = 150 mm

Buchberger Profilsysteme VA.8.95/..F

Corner piece vertical h = variable

Buchberger Profilsysteme VA.8.95/..F

End piece h = variable

Buchberger Profilsysteme VA.8.95/..

Corner piece horizontal with transition floor-floor to floor-wall version W3 and end piece h = 50 mm

Buchberger Profilsysteme VA.8.95/..

T-piece with transition floor-floor to floor-wall version W3 and profile end formation end-piece h = 50 mm

Buchberger Profilsysteme VA.8.95/..

Corner piece horizontal with transition floor-floor to floor-wall version W3

Buchberger Profilsysteme VA.8.95/..

Profile end design end piece h = 50 mm for floor-wall version W3 with corner piece horizontal

formed parts options BBF124/55

Buchberger Profilsystem BBF124/55

Rounded upstand h = min. 150 mm

Buchberger Profilsystem BBF124/55

Cavetto 45° and upstand h = 150 mm

Buchberger Profilsystem BBF124/55

Foil lift h = variable

Buchberger Profilsystem BBF124/100 WD

Foil lift h = variable

Buchberger Profilsystem BBF124/55 W1

Fitting Floor-Wall connection W1
if the expansion joint passes directly on rising building components,
there are at the transition from floor-floor to floor-wall
two corner pieces horizontally required (Z-shaped design).

Buchberger Profilsystem BBF124/55 W4

Fitting Floor-Wall connection W4
if the expansion joint passes directly on rising building components,
there is at the transition from floor-floor to floor-wall
one Profile fitting required. A straight (aligned) profile is therefore given.

Buchberger Profilsystem BBF124/55

Upstand h = 150 mm for floor-wall version W1 with corner piece horizontal

Buchberger Profilsystem BBF124/55

Corner piece horizontal with transition floor-floor to floor-wall version W1

formed parts options kerb

Buchberger Profilsystem VA.8.95/20

Adapted to the course of the kerb (pavement).

Buchberger Profilsystem VA.8.110/47 F

Continuous under the kerb (pavement) and covered with non-slip tear plate (on request).

Buchberger Profilsystem BBF124/55

Superstructure adapted to the course of the kerb. Loose/fixed flange following the sealing level.
