- high load-bearing capacity
- with loose/fixed flange
We are also available by phone for further questions.
resistant to heavy loads, durable leak-proof, noncorrosive, high flexibility (variable lengths, heights and widths), mesh size of the steel grating in 30X10 mm or 30x30 mm possible
outdoor, multi-storey and underground park decks, all industrial applications, shopping centres, railway stations, airports, exhibition halls
hot-dip galvanised steel, high-grade steel V4A (on request)
truck (on request)
gutter end piece (flange all around or upstand), corner piece, T piece, cross piece, gutter drain, 2 lock per grid
A leak-proof welding of several gutter-parts happens in the course of installing at the building site.
Recess gutter body from OK fixed flange min. 75 mm bis max. 90 mm available.
drainage slots are possible (on request).
For stainless steel gutters, the general cleaning and care instructions must be observed (see also www.buprofile.de - Download section).
Our engineers and technicians can be of assistance during installation on request.
- Material thickness fixed flange:
- 6 mm
- Material thickness vertical base:
- 5 mm
- Supply length:
- 3 mtr
- Steel grating width:
- 150 mm
|Article No.||Gutter Height||installation depth (t)|
|ALR.6.150/51||51 mm||75 mm - 90 mm|
|ALR.6.150/66||66 mm||75 mm - 90 mm|
Other heights on request.
