- low profile height
Für weitere Fragen stehen wir auch telefonisch zur Verfügung.
durable leak-proof, noncorrosive, high flexibility (variable lengths, heights and widths), mesh size of the steel grating in 30X10 mm or 30x30 mm possible
outdoor, multi-storey and underground park decks, all industrial applications, shopping centres, railway stations, airports, exhibition halls
high-grade steel V4A (on request)
coating, screed, industrial covering
Rinnen-Endstück (stirnseitig eingeschweißtes Endblech), corner piece, T piece, cross piece, Rinnen-Ablauf, 2 lock per grid
Our engineers and technicians can be of assistance during installation on request.
A leak-proof welding of several gutter-parts happens in the course of installing at the building site.
For stainless steel gutters, the general cleaning and care instructions must be observed (see also www.buprofile.de - Download section).
- Material/sheet thickness:
- 3 mm
- Supply length:
- 3 mtr
- Steel grating width:
- 150 mm
|Article No.||Profile height||Recess (B⨉T)|
|ALR.5.150/50||50 mm||270 ⨉ 60 mm|
|ALR.5.150/60||60 mm||270 ⨉ 70 mm|
